1.Bopet PCR Asclepius Film

Bopet Film

BOPET film, or biaxially oriented polyethylene terephthalate film, is a versatile plastic film made from the polymer PET. It undergoes a process called biaxial orientation, which involves stretching the film in both the machine direction (MD) and transverse direction (TD). This stretching aligns the polymer molecules, resulting in improved mechanical properties such as high tensile strength and dimensional stability. BOPET film is widely used in packaging, electrical applications, labels, tapes, solar panels, and more, thanks to its excellent barrier properties, clarity, and printability.

We produce a wide range of Biaxially Oriented Polyethylene Terephthalate (BOPET) Films. Our total production capacity is 200,000 tons per annum.

Selexible films are offered in thicknesses ranging from 6.5 to 75 microns. These films are available in various types including Plain, Surface Treated, Chemically Coated, Matte, Heat Sealable, Metallizable, Green, Clear, Extra Clear, and many others.

Properties of Bopet Film

》superior mechanical properties;

》Improved resistance to chemicals;

》Good barrier against oxygen;

》Dimensional stability at elevated temperatures;

》Good optical clarity;

》Excellent surface treatment & coatings;

》Excellent surface smoothness;

》Resistance to abrasion

Application of Bopet Film

》Printing & Lamination;

》Pressure Sensitive Tapes;

》Metallizing;

》Holography;

》Industrial Coating;

》Heat Sealable Films;

》Thermal Lamination;

》Lidding;

》Encapsulation;

》Release Film;

》Hot Stamping;

》Retort Applications;

》Cable Wrapping;

》Siliconized Coating;

》Metallic Yarn;

》Electrical & Thermal Insulation;

》Extra Clear Film for Embossing

Bopet PCR Asclepius Film

Film Grade:

R-ESC

Thickness (Microns):

12 μm

Characteristics:

This film grade features a special functional surface with a controlled coefficient of friction. Additionally, the film is manufactured using Post Consumer Recycled (PCR) content, resulting in a reduced carbon footprint. The PCR content levels available are 30%, 50%, 90%, and 100%.

Usage:

This film aids in preventing slippage during storage or palletization, ensuring secure stacking of bags.

more details please download the data sheet bellow:

1. PCR Asclepius Films R-ESC.pdf

Film Grade:

R-DSC-AA

Thickness (Microns):

10 - 50 μm

Characteristics:

F-DSC-AA is a Both Side coated transparent BOPET film. The film is Standard Primer Coated on both sides. The film is made by using Post Consumer Recycle content for a low carbon footprint (PCR content levels: 30, 50, 90 and 100%).

Usage:

This grade of film is used for flexible packaging, specially Designed for FFS machines. The film is suitable for hot fill & pasteurization Usage.

1. PCR Asclepius Films R-DSC-AA.pdf

Film Grade:

R-DSC-AP

Thickness (Microns):

10 - 50 μm

Characteristics:

F-DSC-AP is a Both Side coated transparent BOPET film. The film is one side UPF Chemical coated with the other side being Standard Primer coated.

Usage:

This grade of film is used for flexible packaging, specially Designed for FFS machines. The film is suitable for hot fill & pasteurization Usage.

1. PCR Asclepius Films R-DSC-AP.pdf

Film Grade:

R-DSC-CC

Thickness (Microns):

10 - 50 μm

Characteristics:

F-DSC-CC is a Both Side coated transparent BOPET film. The film is Chemical Coated on both sides. The film is made by using Post Consumer Recycle content for a low carbon footprint (PCR content levels: 30, 50, 90 and 100%).

Usage:

This grade of film is used for flexible packaging, specially Designed for FFS machines.The film is not recommended for hot fill Usages, pasteurization, sterilization or retort.

1. PCR Asclepius Films R-DSC-CC.pdf

Film Grade:

R-HSP

Thickness (Microns):

12 - 25 μm

Characteristics:

R-HSP is co-extruded transparent Heat Sealable polyester film from our Asclepius branded PCR content products. The film is made by using Post Consumer Recycle content for a low carbon footprint (PCR content levels: 30, 50, 90 and 100%).

Usage:

This film is suitable for seal to itself as well as APET/CPET trays. Heat seal side also seals with PVDC.

1. PCR Asclepius Films R-HSP.pdf

Film Grade:

R-MTG

Thickness (Microns):

12 - 15 μm

Characteristics:

R-MTG is a transparent BOPET film. The film is either both sides Untreated or oneside Corona Treated with the other side Untreated. The film is made by using Post Consumer Recycle content for a low carbon footprint (PCR content levels: 30, 50, 90 and 100%).

Usage:

This grade of film is used in vacuum metallization & for further usage in flexible packaging as a barrier substrate.

1. PCR Asclepius Films R-MTG.pdf

Film Grade:

R-AUT

Thickness (Microns):

8 - 50 μm

Characteristics:

R-AUT is a transparent BOPET film. The film is one side Standard Primer Coated and the other side Corona Treated. The film is made by using Post Consumer Recycle content for a low carbon footprint (PCR content levels: 30, 50, 90 and 100%).

Usage:

This grade of film is used for flexible packaging, specially Designed for FFS machines.

1. PCR Asclepius Films R-AUT.pdf

Film Grade:

R-DSC-CP

Thickness (Microns):

10 - 50 μm

Characteristics:

F-DSC-CP is a Both Side coated transparent BOPET film. The film is one side UPF Chemical Coated to provide a modified functional surface with the other side being Chemical Coated. The film is made by using Post Consumer Recycle content for a low carbon footprint (PCR content levels: 30, 50, 90 and 100%).

Usage:

This grade of film is used for flexible packaging, specially Designed for FFS machines.

1. PCR Asclepius Films R-DSC-CP.pdf

Film Grade:

R-CHE/R-CHC

Thickness (Microns):

12 - 50 μm

Characteristics:

This film has one surface Chemically Coated with the other surface being either Untreated or Corona Treated. The film is made by using Post Consumer Recycle content for a low carbon footprint (PCR content levels: 30, 50, 90 and 100%).

Usage:

Conversion & Metallization, Solvent & Water base coating.

1. PCR Asclepius Films R-CHE_R-CHC.pdf

Film Grade:

R-CLR

Thickness (Microns):

9 - 50 μm

Characteristics:

R-CLR is a transparent low haze BOPET film from our Asclepius PCR portfolio. The film is one side Corona Treated with one side Untreated or both sides Untreated. The film is made by using Post Consumer Recycle content for a low carbon footprint (PCR content levels: 30, 50, 90 and 100%).

Usage:

Printing & Lamination, Converting & Metallization, Embossing, Holograms.

1. PCR Asclepius Films R-CLR.pdf

Film Grade:

R-DSC-CA

Thickness (Microns):

9 - 50 μm

Characteristics:

R-DSC-CA is a transparent BOPET film produced with PCR content. The film is one side Chemical Coated with the other side being Standard Primer Coated. The film is made by using Post Consumer Recycle content for a low carbon footprint (PCR content levels: 30, 50, 90 and 100%).

Usage:

This grade of film is used for flexible packaging, specially Designed for FFS machines.

1. PCR Asclepius Films R-DSC-CA.pdf

Film Grade:

R-DSC-EE

Thickness (Microns):

9 - 50 μm

Characteristics:

F-DSC-EE is a Both Side coated transparent BOPET film. Both sides of the film are EXC Chemical coated to provide modified functional surfaces. The film is made by using Post Consumer Recycle content for a low carbon footprint (PCR content levels: 30, 50, 90 and 100%).

Usage:

The film are Specially designed for direct extruded polyethylene adhesion without the need for primer. Used for printing & lamination Usage.

1. PCR Asclepius Films R-DSC-EE.pdf

Film Grade:

R-DSC-MM

Thickness (Microns):

9 - 50 μm

Characteristics:

F-DSC-MM is a Both Side coated transparent BOPET film. The film is Modified Primer coated on both sides. The film is made by using Post Consumer Recycle content for a low carbon footprint (PCR content levels: 30, 50, 90 and 100%).

Usage:

This grade of film is used for flexible packaging, specially Designed for FFS machines. The film is suitable for hot fill & pasteurization Usage.

1. PCR Asclepius Films R-DSC-MM.pdf

Film Grade:

R-DSC-PM

Thickness (Microns):

9 - 50 μm

Characteristics:

F-DSC-PM is a Both Side coated transparent BOPET film. The film is one side UPF Chemical Coated to provide a modified functional surface with the other side being Modified Primer Coated. The film is made by using Post Consumer Recycle content for a low carbon footprint (PCR content levels: 30, 50, 90 and 100%).

Usage:

This grade of film is used for flexible packaging, specially Designed for FFS machines. The film is suitable for hot fill & pasteurization Usage.

1. PCR Asclepius Films R-DSC-PM.pdf

Film Grade:

R-DSC-PP

Thickness (Microns):

9 - 50 μm

Characteristics:

F-DSC-PP is a Both Side coated transparent BOPET film. The film is UPF Chemically Coated to provide a modified functional surface on both sides.Coated. The film is made by using Post Consumer Recycle content for a low carbon footprint (PCR content levels: 30, 50, 90 and 100%).

Usage:

This grade of film is used for flexible packaging, specially Designed for FFS machines. The film is suitable for hot fill & pasteurization Usage.

1. PCR Asclepius Films R-DSC-PP.pdf

Film Grade:

R-ESB

Thickness (Microns):

12 - 23 μm

Characteristics:

This grade have special functional surface so as to provide easy stacking of bags and restrict the slippage while stacking. The film is made by using Post Consumer Recycle content for a low carbon footprint (PCR content levels: 30, 50, 90 and 100%).

Usage:

This film helps during palletizing, storage and stacking of bags in supermarket.

1. PCR Asclepius Films R-ESB.pdf

Film Grade:

R-HTF

Thickness (Microns):

12 - 50 μm

Characteristics:

The film is either both sides Untreated or one side Corona Treated with other side Untreated. It has good thermal stability at elevated temperature. The film is made by using Post Consumer Recycle content for a low carbon footprint (PCR content levels: 30, 50, 90 and 100%).

Usage:

This grade of film is ideal as a transfer foil to transfer designs on paper, textile and plastics.

1. PCR Asclepius Films R-HTF.pdf

Film Grade:

R-IST

Thickness (Microns):

12 - 36 μm

Characteristics:

It has Improved tensile strength and elongation Characteristics. The film is made by using Post Consumer Recycle content for a low carbon footprint (PCR content levels: 30, 50, 90 and 100%).

Usage:

This grade of film is used for Lidding Usage in Dairy products.

1. PCR Asclepius Films R-IST.pdf

Film Grade:

R-PAP

Thickness (Microns):

12 - 50 μm

Characteristics:

R-PAP is a transparent BOPET film. The film is one side Corona Treated with one side Untreated or both sides Untreated. The film is made by using Post Consumer Recycle content for a low carbon footprint (PCR content levels: 30, 50, 90 and 100%).

Usage:

Flexible packaging, Solvent & Water base coating.

1. PCR Asclepius Films R-PAP.pdf

Film Grade:

R-SLC

Thickness (Microns):

19 - 50 μm

Characteristics:

This grade of film has high strength & durability, optical clarity and good thermal dimensional stability. The film is made by using Post Consumer Recycle content for a low carbon footprint (PCR content levels: 30, 50, 90 and 100%).

Usage:

This film grade is specially designed for silicon coating Usages.

1. PCR Asclepius Films R-SLC.pdf

Film Grade:

R-UPF

Thickness (Microns):

12 - 23 μm

Characteristics:

This film has one surface UPF Chemical Coated with the other surface being either Untreated or Corona Treated. The coating done on one side of the film provides excellent anchorage of metal, various inks & adhesives. The film is made by using Post Consumer Recycle content for a low carbon footprint (PCR content levels: 30, 50, 90 and 100%).

Usage:

This grade of film is used for flexible packaging, metallizing and designed for FFS machines. The film is suitable for hot fill Usages, pasteurization, sterilization or retort.

1. PCR Asclepius Films R-UPF.pdf

Film Grade:

R-STF

Thickness (Microns):

14 - 25 μm

Characteristics:

R-STF is a soft touch / velvet feel matte BOPET film. The film is specially designed to laminate high quality graphic media with a velvet feel similar to peach skin. The film is made by using Post Consumer Recycle content for a low carbon footprint (PCR content levels: 30, 50, 90, and 100%).

Usage:

Luxury Packaging, Label, Graphic Advertising Banners and High end stationary products like diary & book covers.

1. PCR Asclepius Films R-STF.pdf

Production Details About Jiangsu Selexible Bopet Film

We are the manufacturer located in Jiangsu, China, and we have been specialized in this area for more than 18 years with SGS and TUV certificate.

The factory covers an area of more than 50, 000 square meters and 6 main production workshops. Using international advanced equipment and production technology, we can produce pet sheets with a thickness between 6.5 to 75 microns.

Bellow is the pictures of our factory:

Packaging and Shipping of Bopet Film to Abroad

* Export standard package in upright packing or suspend packing.

* We can deliver the goods to port or to door(customer's address) through sea shipping, air shipping or express.

Purchasing Notice

For an accurate quotation and more details please contact our Jiangsu Selexible sales team for help !
